Lsp OBPS-113-RK-LL Ice Maker Pull Stop Box

Product Description

The LSP OBPS-113-RK-LL Ice Maker Pull Stop Box provides a sleek and sophisticated finished look. The decorative knob controls the flow of water to the supply line by actuating the valve in a push/pull motion. The box is strong, compact and cost-efficient.

• Patented design moves the angle-stop for icemaker water supply into the wall
• Easy to install vertically, upside down and horizontally
• Eliminates the need for a copper stub out

Product Highlights

This ice maker pull stop box features a unique push-pull handle that opens and closes the valve. Integrated, replaceable valve has a reliable triple O-ring design inlet seal and ball valve design with PTFE seats.

Product Information

Standard Information

• Brand: LSP
• Manufacturer Part Number: OBPS-113-RK-LL

Technical Specifications

• ASME: ASME A112.18.1
• Box Material: Plastic
• Collection: Pull Stop Box
• Connection Size: 1/2
• Fire Rated: No
• Height: 4-1/8
• Length: 3-1/2
• Supply Box Connection Type: PEX
• Supply Box Type: Ice Maker
• UPC: 671436012303
• Water Hammer Arrestor Included: No
• Type: Ice Maker
• Material: Plastic
• Specifications: 40 to 180 deg F Working, 125 psi Working
• Suitable For Use With: Ice Maker
• Width: 4.95 in
• Brand: Aquaflo
