Product Description
The Leviton 1451-2W is a 15 Amp, 120 Volt, Toggle Framed Single-Pole AC Quiet Switch. This residential grade switch features grounding and quickwire push-in & side wiring. Constructed with impact-resistant thermoplastic, it ensures durability and longevity. Ideal for residential applications, it offers easy installation and reliable performance.
- 15 Amp, 120 Volt
- Toggle Framed Single-Pole AC Quiet Switch
- Residential Grade, Grounding
Product Highlights
Durable thermoplastic construction, easy installation with quickwire push-in and side wiring, suitable for residential applications.
Product Information
Standard Information
-
Brand: LEVITON
-
Manufacturer Part Number: 1451-2W
-
Country of Origin: US
Technical Specifications
-
Color: White
-
Voltage: 120 Volts
-
Material: Thermoplastic, Steel
-
Switch Type: Single Pole
-
Switch Style: Toggle
-
Connector Type: Quick Connect
-
Current Rating: 15 Amps
-
Operation Mode: ON-OFF
-
Contact Material: Copper
-
Operating Voltage: 120 Volts
-
Batteries Included?: No
-
Batteries Required?: No
-
Power Rating: 1/2, 2 hp
-
Contact Type: SP
-
Wiring: Push-In, Side
-
Application: Residential
-
Approval: UL, CSA, NOM 057
-
Operating Temperature: -40 to 65 Deg C
-
Grounding Type: Grounding
-
Strap Material: Steel
-
Includes: Ground Screw
-
Poles: 1
-
Grade: Residential Grade
-
Body Material: Thermoplastic
-
Connection: Box mount switch with quick wire push-in, side-wired and ground screw connection
-
Wire Accommodation: Accommodates 12-AWG copper or copper clad wire
-
Temperature Rating: -40 to 65 deg C
-
Certification: UL listed and CSA/NOM certified
-
Actuator: Cam
-
Mounting: Surface
-
Terminal Type: Side and Push-In Wired
-
Contact Rating: 1/2 hp at 120 VAC, 2 hp at 240 VAC
-
Amperage Rating: 15 A
-
Number of Poles: 1
-
Contact Configuration: SP
-
Environmental Conditions: -40 to 65 deg C Operating Temperature
-
HP Rating: 1/2HP-120V
-
Max Amp: 12 Amp
-
Wire Size: up to #12 AWG, #14 AWG in Canada
-
Termination: Quickwire Push-In & Side
-
Standards and Certifications: UL/CSA
-
Torque Range: 14 18 in.-lbs
-
Type: Toggle Switch
-
Voltage Rating: 120 VAC
-
Height (In.): 4.2
-
Width (In.): 1.3
-
Depth( In.): 1.01
-
Voltage (V AC): 125
-
Pole Config: Single-Pole
