Legris 31291013 Push to Connect Fitting

Product Description

Legris 31291013 is a push-to-connect fitting designed for semirigid plastic tubing in pneumatic systems. This fitting features a body made of glass-filled nylon, with nickel-plated brass threaded components and buna-nitrile elastomer seals. Quick and efficient, it allows for a tight, leak-free connection by simply inserting the tubing into its patented stainless steel gripping ring. Each fitting has a plastic release button for easy connections and disconnections that require low force and no tools. The fitting is reusable and does not deform the tubing. Suitable for nylon, polyurethane, polyethylene, or Teflon tubing.

• Max working pressure of 290 psi
• Suitable working temperature range of -4 °F to 175 °F
• Vacuum rating of 28 Hg

Product Highlights

This fitting offers a 360-degree rotation for easy assembly and comes with pre-applied thread sealant on tapered threads.

Product Information

Standard Information

• Brand: Legris
• Part Number: 31291013

Technical Specifications

• End Size: 10 mm Tube(f)
• Height: 39.500 mm
• Material: Nickel-Plated Brass
• Thread Size: 1/4
• Fitting Angle: 90°
• No. of Ends: 2
• End Types: Tubing & BSPT
• Body Material: Nickel-Plated Brass
• Size Type: Metric Sizes
• Hex Size: 15 mm
• Weight: 0.068 LB
• EAN or UPC: 820099232287
