Legris 31070800 Push to Connect Fitting

Product Description

The Legris 31070800 is a push-to-connect fitting designed for easy connections in various plumbing applications. This fitting is suitable for 5/16 or 8 mm O.D. tubing. It features a straightforward design for the quick assembly of tubing for various projects. The Legris brand is known for its reliability in the industry.

• Max. working pressure: 290 psi
• Working temperature: -4 °F to 175 °F
• Vacuum rating: 28 Hg

Product Highlights

This fitting enables seamless connections in pneumatic and other tubing systems, ensuring efficient workflow.

Product Information

Standard Information

• Brand: Legris
• Part Number: 31070800

Technical Specifications

• Material: Nylon Body
• Origin: Plastic Push to Connect Fittings
• End Types: Tubing
• Overall Length: 22.5 mm
• No. of Ends: 4
• Tube O.D.: 5/16 in, 8.000 mm
• Fitting Description: Equal Cross w/ Mounting Holes
• Fitting Angle: 90°
• End Size: 5/16 or 8 mm Tube(f)
• Size Type: Metric, Equal
• Height: 46.000 mm
• Weight: 0.044 LB
• EAN or UPC: 820099217543
