Legris 04992335 Double Female Lockable Vented Ball Valve

Product Description

The Legris 04992335 is a double female lockable vented ball valve designed for reliable operation. This valve helps prevent unintended operation through a locking mechanism. It features a plate that secures the valve body to the valve stem. When padlocked, the valve handle remains stationary.

• Lockable in the closed position with up to three padlocks.
• Standard for use in plumbing and HVAC systems.
• Offers safety during maintenance and repairs.

Product Highlights

This valve is ideal for situations requiring secure flow control. It is particularly useful in HVAC and plumbing applications where safety is a priority.

Product Information

Standard Information

• Brand: Legris
• MPN: 04992335

Technical Specifications

• Temperature Range [Min]: -4 °F
• Temperature Range [Max]: 175 °F
• Pressure [Max]: 580 psi
• Seal Material: Nitrile
• Thread Size: 1 inch
• Connection Type: Female Thread to Female Thread
• Exhaust Port Size (NPT): 1/4 inch
• Body Material: Sand-Blasted Nickel-Plated Brass
