Laing E1-BCANCT1W-06 Autocirc Pump 14 W Replacement LHB08100092

Product Description

The Laing E1-BCANCT1W-06 Autocirc Pump is suitable for potable water systems. The pump uses electronically commutated permanent magnet motor technology, designed to operate only when hot water is needed. It is ideal for retrofit installations, placed under the sink furthest from the water heater.

• Lead-Free
• Quiet operation
• No need for a return line

Product Highlights

This pump efficiently provides hot water on demand, reducing wait times and conserving energy.

Product Information

Standard Information

• Product ID: 290858
• Manufacturer: ITT Corp.

Technical Specifications

• MPN: E1-BCANCT1W-06
• Manufacturer Part Number: LHB08100092
• Applicable Standard: ETL (Canada and US), NSF
• Casing Material: Brass
• Discharge Size: 1/2 inch-14 TPI
• End Connection: 1/2 inch-14 TPI Thread x 1/2 inch-14 TPI Thread
• Impeller Material: Nylon/Polyphenylene Oxide
• Inclusions Features: EPDM O-Ring, Carbon/Ceramic Bearing, Lead-Free Brass Pump Housing
• Input Supply Rating: 115 VAC at 60 Hz
• Overall Dimensions: 4-3/8 inch L x 4-13/32 inch W x 7-7/16 inch H
• Power Rating: 14 W
• Pressure Rating: 145 PSI
• Shaft Seal Details: Mechanical Seal
• Speed Rating: 3450 RPM
• Suction Size: 1/2 inch-14 TPI
• Temperature Rating: 203 Deg F
• Type: Close Coupled, Horizontal/Vertical Mount
• Voltage: 115 VAC
