KROMSCHRODER 84447800 DG 6T-21N Pressure Switch

Product Description

The KROMSCHRODER 84447800 DG 6T-21N is a pressure switch suitable for measuring gas and air pressures, including those from biologically produced methane. This unit is designed with a manual hand wheel for adjusting the switching point and features an automatic reset capability. It includes screw terminals for electrical connections through a one-half inch NPT conduit, along with a one-quarter inch NPT process connection.

• Monitors gas and air pressures
• Adjustable range from 0.2 to 2.4 WC
• Includes a 1/4 NPT connection

Product Highlights

This pressure switch is FM and UL tested and comes with a blue pilot lamp for indicating voltage, ensuring effective monitoring of the pressure system.

Product Information

Standard Information

• Brand: KROMSCHRODER
• MPN: 84447800

Technical Specifications

• Pressure Range: 0.2 - 2.4
• Adjusting Range: 0.5-6 mbar
• Connection Type: 1/4 Female NPT
• Mount: 1/4 NPT
• Contact Type: SPDT
• Reset Type: Auto
• Weight: 0.321 kg
• Enclosure Rating: IP 54
