Kennametal KTN97710H Threading Toolholder Right Hand

Product Description

The KENNAMETAL KTN97710H is a right-hand indexable threading toolholder built for precision external threading operations on CNC lathes and turning centers. Part of the Top Notch series, it features a 1.0 inch shank diameter and a 12 inch overall length with a center-to-cutting-edge distance of 0.688 inches. Constructed from steel, the holder uses a clamp-style insert holding method and accepts N.3L inserts. The A16NER3 toolholder style and integrated coolant-through capability make this holder well-suited for demanding threading applications where chip control and tool life are priorities.

This toolholder is designed for threading applications on production turning equipment where consistent insert indexing and rigid clamping are required. The coolant-through design delivers cutting fluid directly to the insert tip, supporting higher cutting speeds and extended tool life in ferrous and non-ferrous threading work. It is intended for use by machinists and tooling specialists in precision machining environments, including job shops and production facilities requiring repeatable thread form accuracy.

Key Features

• Right-hand cutting orientation for standard external threading setups
• Top Notch series clamp-style insert retention for secure, repeatable indexing
• Accepts N.3L inserts for threading insert compatibility
• Coolant-through design for direct coolant delivery to the cutting zone
• Steel construction for rigidity and durability under threading loads
• A16NER3 toolholder style with 1.0 inch shank diameter and 12 inch overall length

Compatibility

Compatible with N.3L threading inserts in the Top Notch series. Designed as an OEM-style fit for right-hand external threading applications on CNC turning centers and lathes accepting A16NER3-style toolholders.

Installation Notes

Installation should be performed by a qualified machinist or tooling specialist. Ensure the machine spindle is fully stopped and locked out before mounting or adjusting the toolholder. Secure the holder in the turret or tool post according to the machine manufacturer torque guidelines. Verify insert seating and clamp engagement before returning the machine to operation.
