Jomar 100-101 Full Port, 2 Piece, Threaded Connection, 600 WOG

Product Description

The Jomar Valve® 100-101 is a 2-piece ball valve designed for reliable fluid control. It features a full port design and is suitable for applications with a pressure rating of six hundred psi WOG. The valve is constructed with a chrome plated brass ball and includes a brass body and stem along with PTFE seat trim.

• Standard NPT threaded connections
• Features Buna-N and PTFE softgoods
• Engineered for easy operation and maintenance

Product Highlights

This valve is ideal for plumbing and industrial applications, providing precise flow control and durability across various operating conditions.

Product Information

Standard Information

• Manufacturer: Jomar
• MPN: 100-101

Technical Specifications

• Ball Material: Chrome Plated Brass
• Body Material: Brass
• End Style: NPT
• Nominal Size: 1/4 inch
• Pressure Rating: 600 psi WOG
• Inlet to Outlet Length: 1.73 inches
• Top to Inlet Center: 1.69 inches
• Type: 2-Piece
• Trim Material: Brass Stem and PTFE Seat
• Softgoods Material: Buna-N/PTFE
