Johnson Controls VG7551ET+3003D Globe Valve Assembly 2 Way 1/2 in.

Product Description

The Johnson Controls VG7551ET+3003D Globe Valve Assembly is designed for reliable control in HVAC systems. This two-way valve features a half-inch connection and is built for hot water, chilled water, glycol solutions, and steam applications.

• ANSI Class 250 static pressure rating
• Pneumatic actuator with adaptable air connection
• Operating temperature range from thirty-five Fahrenheit to two hundred forty-eight Fahrenheit

Product Highlights

The valve body is made of durable bronze and includes a stainless steel stem for extended life. Its disk seat is crafted from a molded elastomeric material, ensuring a tight seal under varying conditions.

Product Information

Standard Information

• Brand: Johnson Controls
• Part Number: VG7551ET+3003D

Technical Specifications

• Housing: Die-Cast Aluminum
• Service: Hot Water, Chilled Water, 50/50 Glycol Solutions, And Steam For HVAC Systems
• Closeoff Pressure: 339 psig
• Flow Characteristic: Equal Percentage
• Operating Conditions: 35 F To 248 F (2 C To 120 C)
• Actuator Operating Conditions: -20 F To 150 F (-29 C To 66 C)
• Valve Body Static Pressure Rating: ANSI Class 250
• Actuator Connection Type: 1/8 in. NPT barbed fitting for 1/4 in. or 5/32 in. O.D. polytubing air connection
