Johnson Controls M9203-BGA-2 Electric Actuator 27 in-lb Running Torque -22 to 140 Degree F

Product Description

The Johnson Controls M9203-BGA-2 Electric Actuator is designed for control of dampers in HVAC systems. It provides 27 in-lb of running torque and operates efficiently within temperatures ranging from -22 to 140 degrees Fahrenheit. This actuator features a mechanical spring return system that ensures consistent torque output, even without power.

• 27 in-lb running torque
• Spring return system
• Direct mounting

Product Highlights

The Johnson Controls M9203-BGA-2 Electric Actuator is equipped to handle demanding HVAC applications. It mounts directly to a damper shaft without requiring a linkage and includes an optional auxiliary switch for enhanced functionality.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: M9203-BGA-2

Technical Specifications

• Torque: 27 in-lb
• Voltage: 24V AC/DC
• Temperature Range: -22 to 140 degrees Fahrenheit
• Power Consumption: 5VA
• Mounting Type: Direct Mount
• Signal Type: On/Off
• Stroke: 90 Degrees
• Includes: Anti-Rotation Bracket
