Johnson Controls M9108-GGC-2 Motor Actuator 70 lb-in (Non-Spring Return)

Product Description

The Johnson Controls M9108-GGC-2 is a motor actuator designed for HVAC applications. This non-spring return actuator offers a torque of seventy pound-inches and operates at twenty-four volts AC. It features proportional control with a voltage range of zero to ten VDC, suitable for various types of controllers.

• Electronic stall detection enhances reliability by turning off the motor during stall conditions.
• Adjustable rotation allows for precise control of dampers and valves.
• Two auxiliary switches provide additional control options and monitoring of positions.

Product Highlights

The actuator is built for ease of installation on dampers with round or square shafts. It simplifies setup with jumper selectable rotation direction and manual gear release. The integrated position feedback allows for effective closed-loop control.

Product Information

Standard Information

• Brand: Johnson Controls
• MPN: M9108-GGC-2

Technical Specifications

• Torque: 70 lb-in (8 Nm)
• Power Requirements: AC 24 V, 50/60 Hz, DC 24 V
• Operating Conditions: -4°F to 122°F (-20°C to 50°C)
• Electrical Connection: Screw terminals for 22 to 14 AWG
• Auxiliary Switches: 2 x SPDT
• Weight: 3.05 lbs
• Dimensions: 5.05 x 8.3 x 4.55 inches
• Installation Type: Direct or remote mounting
