Iscar 3103154 Replaceable Tip Milling Shank 5/8 in

Product Description

The ISCAR 3103154 is a replaceable tip milling shank designed for use with the Multimaster modular tooling system. Built from steel with a straight shank profile, it accepts a T10 neck thread and features a 0.625 inch neck diameter and a 0.625 inch shank diameter. The overall length is 4.0 inches. This shank serves as the body component that connects exchangeable milling heads to the machine spindle, allowing tool changes without removing the holder from the machine. It is installed by CNC machinists and toolroom technicians in production and job shop environments.

This shank is suited for milling operations in machining centers and CNC mills where the Multimaster system is in use. The 90-degree shank geometry and Weldon flat accommodate secure clamping in standard side-lock holders. The toolholder style designation is MM S-A-L4. It is appropriate for applications requiring repeatable tool changes, tight runout control, and modular flexibility across multiple head configurations.

Key Features

• Replaceable tip design compatible with Multimaster modular system
• T10 neck thread for positive head engagement and repeatable indexing
• 0.625 inch shank diameter with Weldon flat for secure side-lock clamping
• Steel construction for rigidity in milling applications
• 4.0 inch overall length suits standard reach requirements
• No coolant-through configuration

Compatibility

Designed for use within the ISCAR Multimaster modular milling system. Compatible with Multimaster replaceable milling heads using T10 thread interface. Toolholder style MM S-A-L4; manufacturer catalog number MM TS-A-L4.00-C.625-T10.

Installation Notes

Installation should be performed by a qualified CNC machinist or toolroom technician with the machine powered down and spindle locked before mounting or removing the shank. Torque the replaceable head to the neck thread according to the system interface specification before running the spindle. Inspect the T10 thread interface and shank seating surfaces for debris or damage prior to assembly. Follow applicable shop safety procedures and machine tool manufacturer guidelines during setup.
