Iscar 2301404 Indexable Cutoff Blade Double End Neutral

Product Description

The ISCAR 2301404 is an HGFH-style double end neutral indexable cutoff blade engineered for grooving, parting, and turning operations on CNC lathes and turning centers. The blade measures 32 mm in height, 2.4 mm in width, and 150 mm in overall length, accepting DG-series inserts with a 3 mm insert width via a self-grip holding method. The neutral cutting direction suits straight-in parting and grooving work where a left- or right-hand geometry is not required. Machinists and toolroom technicians working with precision turning applications will find the double-end design extends tool body service life by providing two usable cutting positions per blade.

This blade is suited for grooving, parting, and turning operations on workpieces up to 100 mm in diameter. It is compatible with the Do-Grip and Heli-Grip insert series. The blade is appropriate for use in production turning environments, job shops, and precision machining operations requiring consistent, repeatable parting and grooving performance. Its self-grip insert retention method allows quick insert indexing without additional clamping hardware, reducing changeover time during production runs.

Key Features

• Double end design provides two cutting positions per blade body, extending usable tool life
• Self-grip insert holding secures DG-series inserts without additional clamps
• Neutral cutting direction supports straight-in parting and grooving applications
• Maximum workpiece capacity of 100 mm diameter
• Compatible with Do-Grip and Heli-Grip insert series
• Conforms to ISO 13399 cutting tool data representation standards

Compatibility

Designed for use with ISCAR Do-Grip and Heli-Grip series DG-style inserts with a 3 mm insert width. Accepts inserts conforming to the DG.. insert style designation.

Installation Notes

Installation should be performed by a qualified machinist or toolroom technician with the machine powered down and in a locked-out, tagged-out state. Verify that the insert style, width, and series match the blade specifications before seating the insert into the self-grip pocket. Confirm blade shank seating and clamping torque per the machine tool manufacturer guidelines before resuming cutting operations. Follow all applicable shop safety procedures when handling indexable tooling.
