Iscar 2301202 Indexable Cutoff Blade Self Grip

Product Description

The ISCAR 2301202 is an SGFS-style single-end neutral indexable cutoff blade designed for grooving, parting, and turning operations on CNC lathes and turning centers. The blade measures 0.6732 inches in height, 0.063 inches in width, and 4.3307 inches in overall length. It uses a Self Grip insert-holding method, which mechanically locks the insert under cutting forces for repeatable positioning without additional fasteners. This blade is built to ISO 13399 standards and is suited for machinists and toolroom technicians working in production or job-shop environments.

The 2301202 is intended for use in external grooving, cutoff, and turning applications on workpieces up to 1.38 inches in diameter. The neutral cutting direction makes it compatible with standard right-hand tooling setups. Its Self Grip series design accepts inserts with a minimum width of 0.0709 inches and a maximum width of 0.1059 inches, giving the toolholder flexibility across a range of insert geometries within the SGFS family. Typical applications include bar stock parting on gang-tooled lathes and grooving operations requiring close dimensional tolerances.

Key Features

• SGFS blade style with Self Grip insert clamping — no screw required to secure the insert
• Single-end neutral cutting direction for standard right-hand lathe setups
• Accepts inserts from 0.0709 inches to 0.1059 inches wide
• Maximum workpiece diameter of 1.38 inches
• Conforms to ISO 13399 tooling data standards for CAM and tool management system integration
• Compact blade width of 0.063 inches minimizes material loss at cutoff

Compatibility

Designed for use with SGFS Self Grip series inserts with a width range of 1.80 mm to 2.69 mm. Confirm insert series and width compatibility before ordering. No additional compatible model numbers were specified in the product data.

Installation Notes

Installation is performed by qualified machinists or toolroom technicians. Ensure the machine spindle is fully stopped and all power is removed before changing or seating the blade in the toolholder. Verify that the blade is fully seated and clamped in the toolblock to the toolholder manufacturer specifications before resuming cutting. Do not exceed the maximum workpiece diameter of 1.38 inches, as overloading the blade can result in insert ejection or blade fracture.
