Irwin IR8564ZR Hex Bolt Die 20mm X 2.5 Hcs External

Product Description

The IRWIN IR8564ZR is a hex bolt die designed for cutting and restoring external threads on 20mm fasteners with a 2.5mm pitch. Manufactured from hardened carbon steel (HCS), this die delivers the durability needed for repeated use in demanding shop and field environments. The hex-form outer profile measures 1-13/16 inches across, allowing it to be driven with standard die stocks or wrenches. It is suited for licensed machinists, automotive technicians, and maintenance professionals who need to chase or cut metric external threads efficiently and accurately.

This die is specified for use in automotive repair and general machinery maintenance applications where metric 20mm x 2.5mm threaded fasteners are common. It is appropriate for both restoring damaged threads on existing bolts and cutting new external threads on rod stock. The hardened carbon steel construction makes it a reliable choice for production shop use as well as field repair work where thread integrity is critical to assembly safety.

Key Features

• Cuts and restores external threads sized 20mm x 2.5mm
• Hex outer profile at 1-13/16 inches for use with standard die stocks or wrenches
• Hardened carbon steel (HCS) construction for durability under repeated use
• Suitable for automotive repair and machinery maintenance applications
• Sold individually, no minimum quantity beyond one unit

Compatibility

Designed for cutting and chasing external metric threads on 20mm x 2.5mm fasteners and rod stock in automotive and general machinery applications.

Installation Notes

Installation and use of threading dies should be performed by a qualified machinist or trade professional familiar with proper thread-cutting technique. Secure the workpiece firmly before engaging the die, and apply cutting fluid to reduce heat and extend die life. Always verify thread pitch and diameter against the fastener specification before cutting to avoid mismatched threads. Inspect the die for wear or chipping before each use.

Technical Specifications

• Thread Size: 20mm x 2.5mm
• Die Type: Hex External Die
• Outer Profile Width: 1-13/16 inches
• Material: Hardened Carbon Steel (HCS)
• UPC: 042526085642
• Sold As: Each

Standard Information

• Brand: IRWIN
• Manufacturer Part Number: IR8564ZR
