Intermatic T171 SPST 24 Hour 125-Volt Time Switch with Type 1 Indoor Enclosure

Product Description

The Intermatic T171 is a 24-hour time switch designed to handle electrical loads up to forty amps per pole. It operates at 125 volts and features a single-pole single-throw (SPST) switching mechanism. This time switch provides daily automation for lighting and equipment control in commercial, industrial, and residential applications.

• Controls loads up to 40 Amps per pole
• Direct 24-hour control with up to 10 ON/OFF settings each day
• Includes one ON tripper, one OFF tripper, and three day-skipper screws

Product Highlights

This timer switch is designed for wall mounting and comes with a NEMA 1 enclosure for indoor applications. It allows for flexible scheduling while enabling users to skip operation on selected days when loads are not needed.

Product Information

Standard Information

• Brand: Intermatic
• MPN: T171

Technical Specifications

• Voltage Rating: 125 Volts
• Amperage Rating: 40 Amps
• Switch Type: SPST
• Enclosure Type: NEMA 1
• Dimensions: 7.875 inches high x 5.125 inches wide x 3.437 inches deep
• Operating Temperature: -40 to 130 degrees Fahrenheit
• Wattage: 3 Watts
• Mounting Type: Wall Mount
• Max On/Off Cycles: 12 per day
