Intermatic FM/1STUZ-240U 24HR TIMER MOD 240V 21A SPDT

Product Description

The Intermatic FM/1STUZ-240U is a 24-hour timer module designed for control applications up to 21 amps at 240 volts AC. This module integrates easily into machine control panels, circuit boards, or other equipment. It is suitable for heating, ventilation, lighting, and refrigeration systems. The timer allows users to set electronic schedules for HVAC and security systems, making it ideal for both residential and commercial applications.

• Designed for use in 240 VAC systems.
• SPDT switch rated for 21 amps.
• Standard panel mounting for easy installation.

Product Highlights

Efficient management of electrical loads with a compact design.

Product Information

Standard Information

• Brand: Intermatic
• Manufacturer: Intermatic, Inc

Technical Specifications

• Voltage: 240 VAC
• Contact Rating: 21 AMP @ 120 - 250 VAC
• Type: Synchronous Electromechanical
• Height: 2.36 inches
• Width: 2.36 inches
• Depth: 1.25 inches
• Temperature Rating: -40 to 185 degrees F
• Action: SPDT
• Number of Poles: 1
