Ilsco CT-2 Compression Sleeve, Conductor Size 2, Tin Plated, UL, CSA

Product Description

Ilsco CT-2 Compression Sleeve features a conductor size of two gauge. This sleeve is tin plated and approved for UL and CSA standards. It is designed for use in wire termination and ensures a reliable electrical connection.

• Compatible with conductor sizes ranging from two to six gauges.
• Constructed from electro-tin plated high strength seamless copper.
• Suitable for high voltage applications up to thirty-five kilovolts.

Product Highlights

This compression sleeve provides versatility in applications, helping reduce inventory requirements. It identifies the proper compression die for better application efficiency.

Product Information

Standard Information

• Catalog Number: CT-2
• Manufacturer: ECM Industries

Technical Specifications

• Approval: UL 453G, UL 486A/B, CSA
• Barrel Type: Short with Chamfered End
• Body Material: Electro-Tin Plated High Strength Seamless Copper
• Color Code: Brown
• Conductor Material: Copper
• Conductor Size: 2 AWG
• Inner Diameter: 0.31 inches
• Outer Diameter: 0.421 inches
