HYDROLEVEL 650SV CONTROL BOARDS
HYDROLEVEL Hydrolevel 650SV Lvl Control 120V Auto Reset LWCO w/ Short Probe

Hydrolevel 650SV Lvl Control 120V Auto Reset LWCO w/ Short Probe

HYDROLEVEL
Brand: HYDROLEVEL
SKU: 650SV
Availability: In Stock

Ships same day if ordered by 12 pm

Same-day delivery
Greater Boston, MA & Chicago, IL areas
If ordered prior to 4pm local time (Mon-Fri)
$276.39
$276.39
Manuals:
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The Hydrolevel 650SV is a level control with automatic reset, low water cut-off, and a short probe. Designed for hot water boilers, it ensures safe operation by interrupting power immediately in low water conditions. The 650SV model locks out the burner circuit if water remains below the probe for 30 seconds.

  • Automatic reset function
  • Low water cut-off feature
  • Includes a short probe

Product Highlights

This low water cut-off device ensures safe operation of hot water boilers by automatically resetting and testing the burner circuit without lowering the water level. It is particularly useful in preventing boiler damage due to low water levels.

Product Information

Standard Information

  • Brand: Hydrolevel
  • Model: Safgard
Technical Specifications
MPN
650SV
Application
Hot Water Boilers
Voltage
120V
Enclosure
NEMA 1
Max Water Temp
250°F
Max Water Pressure
160 psi
Connection Size
3/4 inch
Control Connection
NPT
Control Reset
Automatic
Ohms Sensitivity
15,000 ohm
Installation Method
Direct to Boiler Tappings
Weight
3.00 lbs
Dimensions
6.2 inches (L) x 6.95 inches (W) x 5.45 inches (H)
