Hydrolevel 45-026 VXT-24 Water Feeder - 24V

Product Description

The Hydrolevel VXT-24 Water Feeder is an automatic device that maintains a safe water level in steam boilers. It monitors the amount of water added and prevents issues related to excessive make-up water.

• Digital feed counter shows the amount of water added.
• Compatible with all probe and float low water cut-offs.
• Programmable settings for feed amount and delay.

Product Highlights

This feeder enhances boiler safety by detecting leaks and allowing timely water additions without manual intervention.

Product Information

Standard Information

• Type: Electronic
• Application: Steam Boilers

Technical Specifications

• MPN: 45-026
• Size: 1/2 inch
• Voltage: 24 volts
• Feed Rate: 2
• Max Pressure: 150 PSI
• Max Vessel Pressure: 15 PSI
• Max Inlet Water Temperature: 150 degrees Fahrenheit
• Power Consumption: 10 VA
• Shipping Dimensions: 6.75 inches depth x 6 inches width x 5.375 inches height
• Weight: 2.861 pounds
