HONEYWELL V8043E1411/U Zone Valve

Product Description

The Honeywell Home V8043E1411/U Zone Valve is a critical component for heating systems. This valve includes a motorized actuator and valve assembly to effectively manage the flow of hot water, cold water, or steam. It is designed for installations with baseboard radiators and convectors. The design supports straightforward installation without requiring disassembly.

• Offers two-position, straight-through control of water flow.
• Suitable for various heating applications including zoning.
• Constructed from durable materials ensuring reliability.

Product Highlights

This zone valve is designed to provide precise control over the heating supply in a home or commercial setting.

Product Information

Standard Information

• Manufacturer: Honeywell
• Brand: Honeywell Home

Technical Specifications

• Application: Zoning
• Connection Type: ProPress
• Size: 1/2 inches
• Voltage: 24V
• Hertz: 50/60
• Flow Coefficient: 3.0 Cv | 3 Kvs
• Operating Temperature (Min): 40 °F
• Operating Temperature (Max): 200 °F
• Ambient Operating Temperature (Max): 125 °F
• Static Pressure Rating: 120 PSI
• Differential Pressure for Close-off (Max): 20 PSI
• Actuator Control Signal: Two position
• Actuator Opening Time: 15 seconds
• Power Loss Action: Valve Closed
• Valve Body Material: Brass
• Valve Body Pattern: Two-way, Straight Through
• Valve Plug Material: Buna-N (NBR) Rubber
• Valve Ball Material: Buna-N (NBR) Rubber
• Valve Seat Material: Brass
• Valve Start Position: Closed
• Valve Stem Material: Stainless Steel
• End Switch: Yes
• Wiring: 18 Leads
• Approvals and Standards: UL Listed, CSA Certified
• Includes: End switch enclosure, Manual Opener
• Product Height: 4 inches
• Product Length: 6.41 inches
• Product Width: 2.34 inches
• Weight: 2.6 lbs
• Fail-Safe Operation Type: Spring return to close
