Honeywell M9185F1002/U Modutrol IV Motor, Spring Return

Product Description

The Honeywell M9185F1002/U is a Modutrol IV motor designed for heating, ventilation, and air conditioning (HVAC) control systems. This spring-return motor operates efficiently on twenty-four volts and consumes twenty VA power. With a torque rating of sixty inch-pounds, it is suitable for various applications in HVAC settings.

• Integral junction box provides NEMA 3 weather protection when mounted appropriately.
• Quick-connect terminals ensure easy and secure electrical connections.
• Field adjustable stroke ranging from ninety to one hundred sixty degrees.

Product Highlights

The Honeywell M9185F1002/U Modutrol motor is ideal for actuating dampers and valves in HVAC systems. It features dual shafts and auxiliary switch options to enhance functionality and adaptability in existing setups.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: M9185F1002/U

Technical Specifications

• Auxiliary Switch: 2
• Power Consumption: 20 VA
• Operating Conditions: -40 F to 150 F (-40 C to 60 C)
• Electrical Connections: Quick-Connect Terminals
• Torque Rating: 60 in-lb
• Control Signal: 135 ohm
• Field Adjustable Stroke: 90 to 160 degrees
