HEATINGVARIOUSMFG-GENERIC Q109 375YM Heating Coil

Product Description

The HEATINGVARIOUSMFG-GENERIC 375YM Heating Coil is effective for hydronic duct heating and cooling. Designed to use hot water as the fluid type, this coil ensures consistent and efficient temperature regulation. It supports an airflow of three hundred seventy-five cubic feet per minute and handles a flow capacity of two gallons per minute.

• Utilizes hot water for temperature regulation
• Features a flanged casing for easy installation
• Effective for both heating and cooling applications

Product Highlights

This heating coil efficiently transfers heat for various HVAC systems, providing reliable performance in both heating and cooling scenarios.

Product Information

Standard Information

• Brand: HEATINGVARIOUSMFG-GENERIC
• MPN: Q109

Technical Specifications

• Fluid Type: Hot Water
• Air Flow: 375 cfm
• Flow Capacity: 2 gpm
• Casing Type: Flanged
• Face Area: 0.5 sq ft
• Fin Type: Sine
• Entering Dry Bulb: 55 Degrees F
• Leaving Dry Bulb: 103.7 Degrees F
• Number of Rows: 2
• Supply and Return Connection: 3/4
• Casing Depth: 4
• Casing Height: 8
• Casing Length: 14
• Fin Height: 6
• Fin Length: 12
• Fin Material: Aluminium
• Fin Thickness: 0.006
• Fins per Inch: 10
