Heatingvariousmfg-generic C661BFA-1C - 24V Intermittent Pilot Ignition Control

Product Description

The Heatingvariousmfg-generic C661BFA-1C Intermittent Pilot Ignition Control is designed for safety in indirect burner ignition and supervision. This control is compatible with all types of gases and is suitable for gas-fired appliances. It operates with a microprocessor that offers reliable control and manages ignition sequences, flame monitoring, and safety shutoffs for intermittent pilot boilers and furnaces.

• Compatible with all gases for versatile application.
• Microprocessor control ensures dependable performance.
• Ideal for boilers, furnaces, and heating appliances.

Product Highlights

This ignition control features a single try for ignition lasting 50 seconds, followed by a 15-second inter-purge and a 4-second pre-purge with no retry timing.

Product Information

Standard Information

• Brand: Heatingvariousmfg-generic
• MPN: C661BFA-1C

Technical Specifications

• Pre-Purge: 4 seconds
• Trial for Ignition: 50 seconds
• Inter-Purge: 15 seconds
• PV Max: 1A
• MV Max: 2A
• Current Draw: 0.2 Amps
• Spark Gap Max: 0.2 inches
• Voltage: 24V
