GREENLEE 17616 Split Point Tap Drill Bit

Product Description

The GREENLEE 17616 is a split point tap drill bit made from high-speed steel. This bit is suitable for drilling, tapping, deburring, and countersinking in a single operation. It performs well when used with a power drill. The design incorporates a back taper to prevent thread damage from over-drilling. Additionally, it has a function for deburring and countersinking past the back taper.

• Suitable for use on mild steel, copper, brass, and aluminum up to ten-gauge.
• Constructed from high-speed steel for durability.
• Designed to handle multiple operations in one step.

Product Highlights

This tap drill bit is versatile and efficient.

Product Information

Standard Information

• Brand: GREENLEE
• MPN: 17616

Technical Specifications

• Material: High Speed Steel
• Point Type: Split Point With Web Thinning
• Thread Type: NC
• Thread Per Inch: 20 TPI
• Thread Size: 1/4-20
• Drill Size: 1/4 inches
• Overall Length: 2-1/4 inches
• Shank Type: Hex
• Shank Diameter: 1/4 inches
• Material Thickness: Up to 10 GA
• Applicable Materials: Mild Steel, Copper, Brass, Aluminum
