Fieldpiece FP-SC440 True-RMS Clamp Meter

FIELDPIECE
Brand: FIELDPIECE
SKU: FP-SC440
Availability: In Stock

Ships same day if ordered by 12 pm

$335.53
$335.53
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The FIELDPIECE FP-SC440 is a clamp meter designed to measure AC current up to four hundred Amps with True RMS accuracy. This functionality makes it suitable for precise AC measurements in various applications. The meter is equipped with an inrush current measurement feature that helps analyze motor startups.

  • Measures AC/DC voltage and DC microamps.
  • Dual display allows for simultaneous readings.
  • Backlight for enhanced visibility in low-light conditions.

Product Highlights

This clamp meter provides comprehensive measurement options, including temperature in both Fahrenheit and Celsius, capacitance, resistance, and frequency measurements using leads or clamp. Non-contact voltage detection and continuity testing capabilities are integral to this device, making it an essential tool for HVAC technicians, electricians, and plumbing professionals.

Product Information

Standard Information

  • Brand: Fieldpiece
  • MPN: FP-SC440
Technical Specifications
Display
5000 count dual display
Backlight
60-second duration with auto-off
Measurement Rate
3.3 times per second
Operating Environment
32°F to 122°F
Storage Temperature
-4°F to 140°F
Accuracy
Stated accuracy @ 73°F ±9°F
Battery Life
100 hours typical alkaline
Dimensions
233mm (H) x 79mm (W) x 45mm (D)
Weight
Approx. 315g including battery
Voltage AC Range
500 mV to 600V
Voltage DC Range
500 mV to 600V
Inrush Current Measurement Period
100 ms
Temperature Range
-30°F to 932°F
Resistance Range
Up to 50 Mega Ohms
Frequency Range
10 Hz to 1 MHz
