Fafnir VFTD5/8 VFTD Series 2-Bolt Flange Unit

Product Description

The Fafnir VFTD5/8 is a reliable 2-Bolt Flange Unit designed for various applications including agriculture, conveyors, and food processing. This unit features a shaft diameter of zero point six two five inches and incorporates a non-relubricatable design which simplifies its maintenance.

• Two-bolt flange for easy mounting
• Contact seals to prevent contamination
• Durable cast iron housing

Product Highlights

This flange unit is suited for normal-duty operations and features an eccentric locking collar for secure shaft attachment.

Product Information

Standard Information

• Brand: Fafnir
• MPN: VFTD5/8

Technical Specifications

• Shaft Diameter: 0.625 in
• Lubrication: Non-Relubricatable
• Housing Length: 3 3/16 in
• Flange Type: 2-Bolt Flange
• Duty: Normal-Duty
• Bearing Type: Ball Bearing
• End Type: Open End
• Bolt Circle Diameter: 2.5 in
• Housing Height: 2 3/32 in
• Overall Width: 1 1/4 in
• Seal Type: Contact Seals
• Housing Material: Cast Iron
• Weight: 0.565 LB
• EAN/UPC: 87796056596
