Eklind 103520 Ball End Hex Impact Bit Holder 1/4 Drive

Product Description

The EKLIND 103520 is a ball end hex impact screwdriver bit holder designed for use with power impact drivers and drills. It measures 3 inches in overall length with a 1/4 inch drive and accepts a 10 mm hex ball end tip. Constructed from alloy steel, this bit holder is built to withstand the rotational stress and percussion forces generated by impact tools. The ball end geometry allows fastening at angles up to approximately 25 degrees off-axis, which is useful in confined or obstructed work areas. HVAC technicians, electricians, plumbers, and general tradespeople use this bit holder when driving hex fasteners with impact-rated power tools.

This bit holder is suited for residential and light commercial service work where a 10 mm hex ball end fastener is required and access is limited. The 1/4 inch drive shank is compatible with standard quick-change impact driver chucks. It is sold as a single piece and is appropriate for tool belt or service van inventory. The 3 inch length provides added reach without sacrificing stability during high-torque impact driving.

Key Features

• Ball end hex tip allows off-axis driving in tight or restricted spaces
• 10 mm hex specialty point size for common metric fastener applications
• 1/4 inch drive shank fits standard quick-change impact driver chucks
• Alloy steel construction rated for impact tool use
• 3 inch overall length provides extended reach
• Non-magnetic design prevents unintended fastener retention

Compatibility

Designed as an OEM-style replacement bit holder for 1/4 inch drive impact drivers and power screwdrivers accepting ball end hex bits. Replaces MSC 97868764.

Installation Notes

Insert the 1/4 inch shank into the impact driver chuck until it seats and locks. Ensure the tool is powered off and any stored energy is released before changing bit holders. This bit holder is intended for impact-rated tools only and should not be used in standard drill-driver applications where impact-rated tooling is not required. Inspect the bit tip and shank for wear or cracking before each use.
