Eaton XTCEXRLG Reversing Contactor

Product Description

The EATON XTCEXRLG is a reversing-type contactor designed for motor control applications requiring forward and reverse operation. Reversing contactors combine two interlocked contactors in a single assembly, switching the phase sequence to change motor rotation direction. This unit is built for installation in motor control centers, control panels, and industrial enclosures. Licensed electricians and industrial control technicians are the primary installers. The reversing configuration eliminates the need to wire two separate contactors with external interlock wiring, simplifying panel layout and reducing installation time.

This contactor is suited for industrial and commercial motor control applications where reversible drive operation is required. Typical use cases include conveyor systems, hoists, pumps, and HVAC equipment requiring reversible motor operation. It is designed for installation in motor control panels and enclosures where reliable phase-reversal switching is needed. The XTCEXRLG fits into the EATON XT series contactor line, following standard IEC-style mounting and connection conventions.

Key Features

• Reversing-type configuration for forward and reverse motor control in a single unit
• Integrated mechanical and electrical interlock to prevent simultaneous closure of both contactors
• IEC-style design for compatibility with standard industrial control panel layouts
• Part of the EATON XT series contactor family for consistent replacement and service

Compatibility

Designed as an OEM-style replacement or new-installation reversing contactor within the EATON XT series motor control product line. Verify coil voltage, pole configuration, and current rating against the application requirements before installation.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. Disconnect and lock out all power sources before working on any contactor or motor control circuit. Verify that coil voltage matches the control circuit supply before energizing. Do not bypass or defeat the interlock mechanism on a reversing contactor assembly.

Technical Specifications

• Type: Reversing Contactor
• UPC: 01508101571

Standard Information

• Brand: EATON
• Manufacturer Part Number: XTCEXRLG
