Eaton XTCEXRLC Auxiliary Contact Block

Product Description

The EATON XTCEXRLC is an auxiliary contact block designed to expand the switching and signaling capability of compatible EATON contactors. The block mounts directly to the contactor body and adds supplemental contact positions for control circuit wiring, interlocking, or status indication. Licensed electricians and industrial controls technicians install this accessory during new panel builds or as a field upgrade when additional control contacts are required. It is a standard add-on component in motor control centers, control panels, and automated equipment where the base contactor does not carry enough auxiliary contacts for the application.

The XTCEXRLC is specified for use with the XTCE018C and XTCE032C EATON contactors. These contactor frames are commonly installed in commercial and light industrial motor control applications including HVAC equipment, pumping systems, and general-purpose motor loads. The auxiliary contact block attaches without tools in most configurations, integrating directly into the contactor assembly.

Key Features

• Adds auxiliary contact positions to base contactor for control circuit expansion
• Direct-mount design integrates with XTCE018C and XTCE032C contactor frames
• Suitable for status indication, interlocking, and safety circuit wiring
• Compact block form factor fits within standard panel and MCC enclosures

Compatibility

Designed for use with the EATON XTCE018C and XTCE032C contactors as a factory-specified auxiliary contact expansion accessory.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and the panel or equipment manufacturer's documentation. De-energize and lock out the panel before attaching or removing the auxiliary contact block. Verify contact ratings are appropriate for the control circuit voltage and current before wiring. Do not exceed the rated switching capacity of the auxiliary contacts.

Technical Specifications

• UPC: 01508283109

Standard Information

• Brand: EATON
• Manufacturer Part Number: XTCEXRLC
