Eaton XTCE012B10A 3-Pole Non-Reversing Contactor 120V 12A

Product Description

The Eaton XTCE012B10A is a 3-pole non-reversing contactor designed for reliable operation in industrial applications. This contactor serves at a voltage of 110 to 120 volts alternating current (VAC) and a maximum load of twelve amps. It is ideal for use in electrical assemblies, panels, and original equipment manufacturers (OEMs).

• Voltage rating: 110-120 VAC, 50/60 Hz
• Contact configuration: 1 normally open (NO)
• Compact size suitable for tight installations

Product Highlights

This contactor allows efficient control of electrical circuits. It is specifically engineered for durability and long-lasting performance.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: XTCE012B10A

Technical Specifications

• Catalog Number: XTCE012B10A
• Coil Voltage: 110-120 VAC
• Maximum Load Current: 12 A
• Contact Configuration: 1 NO
• Number of Poles: 3
• Size: 45 mm
• Frequency Rating: 50/60 Hz
• Dimensions: 1.77 inches W x 2.95 inches D x 2.68 inches H
• Environmental Rating: IP20
• Operating Temperature: -13 to 122 degrees Fahrenheit
• Standards/Approvals: CE Marked, RoHS Compliant, UL Listed, CSA Certified
