Eaton CN35DN2AB CN35 Electrically Held Lighting Contactor 30A 2 Pole

Product Description

The Eaton CN35DN2AB is an electrically held lighting contactor designed for efficient control of lighting loads. This model handles a maximum current of thirty amps and is ideal for applications in commercial and industrial settings. Suitable for use with filament and ballast lamp loads, it ensures reliable operation and safety.

• Electrically held design
• Rated for 30 Amp contact rating
• Two-pole configuration with one normally open contact

Product Highlights

This contactor features a coil voltage of 110 to 120 VAC, suitable for both 50 and 60 Hz applications. It is built to withstand high inrush currents typical of tungsten lamp loads without risk of contact welding.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Catalog Number: CN35DN2AB
• Contact Rating: 30 A
• Coil Voltage: 110/120 VAC
• Frequency Rating: 50/60 Hz
• Dimensions: 3.49 in L x 2 in W x 3.88 in H
• Enclosure Type: Open
• Number of Poles: 2
• Application: Commercial buildings, industrial plants, lighting controls
