Eaton C25END430T Definite Purpose Control Contactor 30A 24 VAC

Product Description

The Eaton C25END430T is a definite purpose control contactor designed for HVAC applications. This model operates at 30 amps and uses a coil voltage of 24 VAC. It features a four-pole configuration and is suitable for various electrical assemblies and control panels.

• Quick-connect terminal type for easy installation.
• Open enclosure with a metal mounting plate.
• Designed for 50/60 Hz frequency operation.

Product Highlights

This contactor is ideal for industrial applications where reliable operation is required.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• MPN: C25END430T
• Voltage: 24 VAC
• Amperage: 30 Amp
• Poles: 4
• Enclosure Type: Open with Metal Mounting Plate
• Coil Voltage: 24 V
• Dimensions: 3.38 in L x 2.68 in W x 3.75 in H
• Weight: 2.3 lb
• Application: Electrical Assemblies, Panels and EOEMs
• Connection Type: Quick
• Operating Temperature: 150 deg F
• Operating Cycles: 300000
