E. James 5L760 FHP V-Belt

Product Description

The E. James 5L760 is a fractional horsepower V-belt designed for general industrial use. This belt features a robust construction with a wrapped design that utilizes rubber and polyester materials for enhanced durability.

• Minimum pulley pitch diameter: 3.5 inches
• Outside length: seventy-six inches
• Resistance properties include heat, oil, and static conductive

Product Highlights

The E. James 5L760 FHP V-belt is ideal for various industrial applications, providing reliable performance under demanding conditions.

Product Information

Standard Information

• Brand: E. James
• MPN: 5L760

Technical Specifications

• Item: FHP V-Belt
• Belt Type: 5L
• Construction: Wrapped
• Material: Rubber, Polyester
• Number Of Ribs: 1
• Thickness: 3/8 inches
• Top Width: 21/32 inches
• Maximum Operating Temperature: 194°F
• Minimum Operating Temperature: -22°F
• Reinforcing Cord Material: Polyester
• Standards: ARPM
• Tensile Strength: 5400 N/mm
• V-belt Section: 5L
• Compatible Devices: Car
