Product Description
The DURAVENT 7DT-18 DuraTech 7-inch diameter chimney pipe is designed for appliances tested and listed for use with a 2100°F HT chimney system. This double-wall, all-fuel chimney pipe is suitable for wood stoves, fireplaces, furnaces, boilers, ranges, water heaters, and other appliances fueled by wood, oil, coal, or gas. It features twist-lock connections for a secure fit.
- For Class A Chimney Pipe
- Designed for Use with Appliances Fueled by Wood, Oil, Coal, or Gas
- UL Listed
Product Highlights
DuraTech chimney pipe ensures safety and performance with its double-wall construction and Thermal Tech blanket insulation.
Product Information
Standard Information
-
Brand: DURAVENT
-
Manufacturer Part Number: 7DT-18
Technical Specifications
-
Inner Diameter: 7"
-
Outer Diameter: 9"
-
Material: Galvanized Steel
-
Inner Pipe Material: 430 Stainless Steel
-
Outer Pipe Material: Galvalume
-
Insulation Type: Thermal Tech
-
Pipe Class: Class A
-
Pipe Shape: Round
-
Vent Construction: Double Wall
-
Fuel Type: All Fuel, Coal, Gas, Oil, Wood
-
Application: Appliance, Boiler, Fireplace, Furnace, Ranges, Water Heater, Wood Stove, Zero-Clearance Fireplace
-
Approved for Commercial Use: No
-
Certifications: UL
-
UL Listing Number: UL 103 HT, ULC S604
-
Length: 18 in.
-
Pipe Inside Diameter: 7 in.
-
Pipe Length: 18 in.
-
Inner Pipe Gauge: 25
-
Outer Pipe Gauge: 26
-
Clearances: A minimum of 2-Inch clearance to combustibles is required
-
Outer Wall: .016" galvanized steel
-
Inner Wall: .020" galvanized steel
-
Insulation: Insulated by a layer of ceramic refractory blanket
