Ducane 16D16 16 SEER Condenser Concord

Product Description

The Ducane 16D16 is a louvered split system air conditioner designed for residential use. It has a cooling capacity of 1.5 ton and operates at 208/230 VAC with a single-phase, 60 Hz power supply.

• ENERGY STAR certification provides potential savings.
• Permanently lubricated fan motor requires no annual maintenance.
• OmniGuard technology protects against corrosion.

Product Highlights

This model is equipped with a heavy-duty compressor and is designed for reliable performance.

Product Information

Standard Information

• Brand: Ducane
• Manufacturer: Allied Air Enterprises

Technical Specifications

• Nominal Capacity: 1.5 ton
• SEER Rating: 16
• Power Source: 208/230 VAC, 1 ph, 60 Hz
• Sound Level: 73 dBA
• Refrigerant Type: R-410A
• Dimensions: 24-1/4 inches W x 24-1/4 inches D x 29 inches H
• Material: Galvanized Steel
• Motor HP: 1/10 hp
• Fuse Size: 20 A
• Discharge Line Size: 3/8 inches
• Suction Line Size: 3/4 inches
• Certifications: AHRI Certified, ENERGY STAR Certified, ETL Listed
