Donaldson P560694 Spin-On Fuel Filter

Product Description

The Donaldson P560694 is a spin-on fuel filter that efficiently removes contaminants from fuel systems. This filter is designed for hydraulic applications and is compatible with Applied filter carts. It features a high dirt holding capacity to extend service life, meeting or exceeding original specifications. It is ideal for use in oil transfer setups, especially in cold conditions where oil viscosity may be high.

• Hydraulic spin-on design
• 3.66 inches outer diameter
• 1-12 UN thread size

Product Highlights

This filter is a reliable choice for maintaining proper fuel filtration and supporting equipment performance.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: P560694

Technical Specifications

• Element Description: Hydraulic Spin-On
• Length: 5.35 inches (136 mm)
• Outer Diameter: 3.66 inches (93 mm)
• Media Type: Synthetic
• Thread Size: 1-12 UN
• Gasket ID: 2.42 inches (61.5 mm)
• Gasket OD: 2.81 inches (71.5 mm)
• Efficiency Beta: 23 Micron @ Beta 1000
