Donaldson P554004 Spin-On Fuel Filter

Product Description

The Donaldson P554004 is a spin-on fuel filter designed for durability and reliability in fuel systems. This filter features a full-flow design suitable for various applications in heavy-duty machinery.

• Outside diameter of four point twenty-five inches
• Full-flow filtration
• Thread size of one and one-eighth to sixteen UN

Product Highlights

The P554004 filter provides excellent filtration performance by removing contaminants from the fuel, ensuring optimal engine performance.

Product Information

Standard Information

• Brand: Donaldson
• Part #: 100180395

Technical Specifications

• Efficiency Test Standard: SAE J1858
• Gasket Outer Diameter: 3.9 in, 99 mm
• Length: 10.31 in, 262 mm
• Gasket Inner Diameter: 3.54 in, 90 mm
• Outer Diameter: 4.25 in, 108 mm
• Media Type: Cellulose
• Collapse Burst Pressure: 149.39 psi, 10.3 bar
• Primary Application: CAT 2P4004 (Not for EURO5/6 engines after 01/2019)
