Donaldson P551756 Spin-On Fuel Filter

Product Description

The Donaldson P551756 is a spin-on fuel filter designed for effective filtration in engines. It measures three point six seven inches in outer diameter and has a thread size of one to twelve UN. This product ensures reliable performance and contributes to the longevity of your engine.

• 3.67 in outer diameter
• 1-12 UN thread size
• Spin-on style for easy replacement

Product Highlights

This fuel filter meets SAE J1858 efficiency standards and features a bypass valve for enhanced functionality.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: P551756

Technical Specifications

• Primary Application: CASE/CASE IH 404886R1
• Outer Diameter: 3.67 in (93.21 mm)
• Length: 3.78 in (96.11 mm)
• Efficiency Test Standard: SAE J1858
• Bypass Valve: Yes
• Bypass Valve Setting HR: 10.15 psi (0.7 bar)
• Bypass Valve Setting LR: 7.25 psi (0.5 bar)
• Gasket ID: 2.46 in (62.53 mm)
• Gasket OD: 2.83 in (71.98 mm)
• Weight: 0.9 lb
• EAN or UPC: 742330137949
