Donaldson P551204 Spin-On Fuel Filter

Product Description

The Donaldson P551204 is a spin-on fuel filter designed for effective filtration in various applications.

• Outer diameter measures three point six seven inches.
• Thread size is one to twelve UN.
• Rated for efficiency of forty-seven microns at Beta two hundred.

Product Highlights

This spin-on style filter is suitable for REXNORD 493308 applications.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: P551204

Technical Specifications

• Outer Diameter: three point six seven inches (93.2 mm)
• Efficiency Beta: forty-seven micron @ Beta 200
• Bypass Valve: Yes
• Length: three point seven six inches (95.5 mm)
• Thread Size: one to twelve UN
• Bypass Valve Setting HR: fourteen point five psi (1 bar)
• Bypass Valve Setting LR: eleven point six psi (0.8 bar)
• Gasket I.D.: two point four six inches (62.5 mm)
• Gasket O.D.: two point eight three inches (72 mm)
