Donaldson P550425 Spin-On Fuel Filter

Product Description

The Donaldson P550425 is a spin-on fuel filter designed for effective filtration in various applications. This filter measures four point two nine inches in outer diameter and has a thread size of one three eighths by sixteen UN. It is constructed with cellulose media for optimal filtration performance.

• Gasket ID of three point six two inches
• Full-flow design for efficient fuel delivery
• Compatible with Volvo 4775565

Product Highlights

This product features a full-flow design, which ensures that fuel passes through the filter efficiently, minimizing any potential disruptions in fuel delivery.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: 100180122

Technical Specifications

• Length: 10.35 inches (263 mm)
• Outer Diameter: 4.29 inches (109 mm)
• Gasket OD: 3.98 inches (101 mm)
• Gasket ID: 3.62 inches (92 mm)
• Thread Size: 1 3/8-16 UN
• Collapse Burst: 120.38 psi (8.3 bar)
• Efficiency 50%: 5 micron
• Efficiency 99%: 21 micron
• Efficiency Test Standard: SAE J806
• Media Type: Cellulose
• Primary Application: VOLVO 4775565
• Weight: 2.4 LB
• EAN or UPC: 742330107744
