Donaldson P169078 Spin-On Fuel Filter

Product Description

The Donaldson P169078 Spin-On Fuel Filter provides reliable filtration for various engines and machinery. Designed for efficiency, it features a diameter of three point eight two inches and a thread size of one and three eighths by twelve UN. This filter uses synthetic media to ensure effective contamination removal.

• Outer Diameter: Three point eight two inches
• Thread Size: One and three eighths by twelve UN
• Media Type: Synthetic

Product Highlights

This filter is ideal for diesel engines, offering excellent performance in various applications, especially in agricultural and construction machinery.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: 100178352

Technical Specifications

• Outside Diameter: Three point eight two inches (97 mm)
• Gasket OD: Two point seven six inches (70 mm)
• Gasket ID: Two point four eight inches (63 mm)
• Length: Four point four seven inches (113.54 mm)
• Efficiency Beta: 23 Micron @ Beta 1000, 7 Micron @ Beta 2
• Primary Application: JOHN DEERE AM102723
• Weight: 0.6 LB
• EAN or UPC: 742330018996
