Donaldson P167944 Spin-On Fuel Filter

Product Description

The Donaldson P167944 is a spin-on fuel filter designed for oil transfer applications. This product features a standard thread size of 1 1/2-16 UN, with an outer diameter of four point eighty-seven inches. It is compatible with several filter series including W023, HBK05, SP50/60, SP80/90, and SP100/120.

• Increased dirt holding capacity for longer element or cartridge life
• Meets or exceeds original filter element specifications
• Designed for easy installation and replacement

Product Highlights

This filter provides reliable protection against contaminants, essential for maintaining engine performance and longevity.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: P167944

Technical Specifications

• Outer Diameter: 4.87 inches (123.69 mm)
• Length: 6.66 inches (169.16 mm)
• Thread Size: 1 1/2-16 UN
• Media Type: Synthetic
• Efficiency: 13 Micron @ Beta 1000
• Weight: 2.9 lb
• Gasket ID: 4.72 inches (120 mm)
• Gasket OD: 5.04 inches (128 mm)
