Donaldson P165705 Spin-On Fuel Filter

Product Description

The Donaldson P165705 is a Spin-On Fuel Filter designed for high flow applications. It features a heavy-duty steel body and a die-cast top plate, providing durability and performance. The filter incorporates a special head-to-canister O-ring seal to prevent leakage and uses Buna-N seals for reliability. It is suited for various engine types and operates under working pressures of up to three hundred fifty psi, with a static burst rating of eight hundred psi.

• 4.76 inches outside diameter
• 1 3/4-12 UN thread size
• Hydraulic Spin-On style

Product Highlights

The Donaldson P165705 Fuel Filter has increased dirt holding capacity for extended element life and meets or exceeds original specifications.

Product Information

Standard Information

• Brand: Donaldson
• MPN: P165705

Technical Specifications

• Efficiency Beta: 23 Micron @ Beta 1000, 7 Micron @ Beta 2
• Outer Diameter: 4.76 inches (121 mm)
• Length: 11.63 inches (295.4 mm)
• Thread Size: 1 3/4-12 UN
• Media Type: Cellulose
• Weight: 3.9 pounds
• Gasket ID: 3.11 inches (79 mm)
• Gasket OD: 3.39 inches (86 mm)
