Donaldson P165672 Spin-On Fuel Filter

Product Description

The Donaldson P165672 is a spin-on fuel filter designed for high flow applications. It features a heavy-duty steel body with a die-cast top plate, ensuring strength and durability. The O-ring seal between the head and canister is specifically engineered to prevent leakage. This filter accommodates working pressures up to three hundred fifty psi and is rated for a static burst pressure of eight hundred psi. The flow range of the filter can go up to fifty gallons per minute.

• Heavy-duty steel construction
• Designed for high flow applications
• Leak-proof O-ring seal

Product Highlights

This spin-on fuel filter has an increased dirt holding capacity for longer service life and meets or exceeds OEM specifications.

Product Information

Standard Information

• Brand: Donaldson
• Part Number: 100178248

Technical Specifications

• Outside Diameter: 4.76 inches
• Length: 11.63 inches
• Thread Size: 1 3/4-12 UN
• Efficiency Beta: 50 Micron @ Beta 1000, 14 Micron @ Beta 2
• Media Type: Synthetic
• Weight: 4.39 lbs
• Filter Series: HMK05/25
• Primary Application: LEROI 438931
