Donaldson P164384 Spin-On Fuel Filter

Product Description

The Donaldson P164384 is a Spin-On Fuel Filter designed for effective dirt holding and filtration. Its heavy-duty steel body and die-cast top plate provide durability and strength. The O-ring seal at the head-to-canister connection minimizes leakage, ensuring reliable performance. With Buna-N seals as a standard feature, this filter operates efficiently under high pressures.

• 3.82 inches Outside Diameter
• 1 3/8-12 UN Thread Size
• Flow capacity up to 35 gallons per minute

Product Highlights

This filter meets or exceeds original equipment specifications, providing an increased dirt holding capacity for extended element life.

Product Information

Standard Information

• Brand: Donaldson
• Part #: 100178173

Technical Specifications

• Media Type: Synthetic
• Outer Diameter: 3.82 inches
• Length: 9.44 inches
• Thread Size: 1 3/8-12 UN
• Efficiency Beta: 23 Micron @ Beta 1000, 7 Micron @ Beta 2
• Filter Series: HMK04/24
• Weight: 2.6 pounds
• EAN or UPC: 742330016206
