Dodge 3020X60MM18X4.4MM | Taper Lock Bushing

Product Description

The Dodge 3020X60MM18X4.4MM is a taper lock bushing designed for secure and effective power transmission. Crafted with precision, it features a bore size of sixty millimeters. This bushing is suitable for various industrial applications where reliable connectivity is essential.

• Easy on and easy off installation.
• Compact design that facilitates flush mounting.
• Designed without protruding parts for safer operation.

Product Highlights

This taper lock bushing is ideal for applications requiring stable mounting and efficient load transfer.

Product Information

Standard Information

• Brand: Dodge
• Part Number: 3020X60MM18X4.4MM

Technical Specifications

• Bushing Series: 3020
• Bore Size: 60 mm
• Bore Type: Metric
• Torque Capacity: 2000 lbf
• Wrench Torque: 66.66 lbf
• Large Diameter: 4 1/4 in
• Length Through Bore: 2 in
• Material: Sintered Steel
• Keyway Size: 18 mm x 4.4 mm
• Capscrew Size: 5/8 x 1 1/4
• Cap Screws: 2
• Bolt Circle Diameter: 4 in
• Weight: 4.35 LB
• EAN or UPC: 782475530373
