Dig 720A-000 7x0a 2 Station Battery Operated Controller

Product Description

The DIG 720A-000 waterproof battery operated controller is designed for challenging sites without AC power for above or below grade installation. The controller includes wire connections for master valve, rain sensor, and up to six DC latching solenoids. Powered by two AA alkaline batteries that last for more than one season.

• Designed for challenging sites without AC power for above or below grade installation.
• Powered by two AA alkaline batteries with a safe period of 60 seconds to replace batteries without losing settings
• Operates up to six stations, master valve, and a sensor. Four Independent programs with five start times per each program

Product Highlights

Offers economical and reliable results with programming versatility and operation simplicity. Features seven buttons with a large, easy-to-read display, and simple icon-based programming.

Product Information

Standard Information

• Brand: DIG
• Manufacturer Part Number: 720A-000

Technical Specifications

• Brand: DIG
• Product Type: Battery Operated (DC) Valve Mounted Controllers
• Expandability: Fixed
• Power Source: Battery Operated
• Number of Programs: 4
• Start Times Per Program: 5
• Max Station Run Time (HRS): 6
• Indoor: Yes
• Outdoor: Yes
• Sensor Compatible: Rain
• Rain Sensor Compatible: Yes
• Application: Light Commercial|Commercial
• Warranty: 3 Years
• Series: 7X0A
• Zones: 2
• Enclosure Type: Waterproof
• Type: DC
• Body: IP68
• Number of stations: two, four, and six and includes master valve and rain sensor
• Power source: two AA alkaline batteries (not included)
• Power input per valve: constant 11 volt
• Completely waterproof (IP68 certified): can operate in harsh environments
• Seven keypad buttons with integrated liquid crystal display: None
• Wire configurations: up to six 18" red wires labeled for each valve, one black wire for master valve, two white wires for common and one looped yellow wire for sensor connections
• Temperature range: 38°F to +130°F (3°C to +54°C)
• Sensor connection: normally closed 6" (15 cm) looped yellow wire (16 AWG)
• Materials: high-impact plastic
• Used with: S-305DC 7-12 VDC normally closed, two-way latching solenoid and 30-92X adapters
• 2 DC Latching Solenoid Connections: (Solenoids sold separately)
• Power input: constant 11 volt
• Program mode: Seven keypad buttons with integrated liquid crystal display
• Mounting options: solenoid or valve box mounting
• Valve type: actuators, anti-siphon or globe valves (NPT or BSP)
• Department: IRRIGATION
