DANFOSS 114N1418 Optyma™ Condensing Unit Bare Unit

Product Description

The DANFOSS 114N1418 Optyma condensing unit is designed for low back pressure applications and operates with R404A refrigerant. This bare unit includes a compressor with a power supply of one hundred fifteen volts, single phase, and sixty Hertz, featuring fixed speed capacity control. It is equipped with a fan, condenser, and receiver for effective heat exchange and cooling performance.

• Segment usage: Low Back Pressure
• Refrigerants: R404A
• Compressor power supply: 115/1/60 V

Product Highlights

Efficient heat exchange and reliable cooling for commercial applications.

Product Information

Standard Information

• Manufacturer: Danfoss
• Part Number: 114N1418

Technical Specifications

• Air flow @ 60Hz: 830 m³/h
• Compressor model: SC15CLX.2
• Condenser type: BM72
• Fan blade size: 254 mm
• Fan current @ 60Hz: 0.8 A
• Fan power consumption @ 60Hz: 73 W
• Fan power output @ 60Hz: 16 W
• Voltage 60Hz: 115 V (max), 95 V (min)
